OFFICE – Professional

  • Uniformity of all interior doors and frames – including stairwells and double egress frames
  • Economical solution without sacrificing performance or quality
  • Fire rated sidelights and borrowed lights available
  • Ideal for either wood stud or steel stud framing
Door Frame uses for Office buildings series arrow classic s classic adjustable kerferd adjustable kerfed double egress pocket trim kit
Frequency S C A CK AK DE P
Common Areas Main Entrance H • • • • • • •
Secondary Entrance M • • • • • • •
Corridor Offices M O O O P • • •
Interior Offices L P O O O • • •
Restrooms M P O O O • • •
Meeting Rooms L O O O P • • •
Closet SS/PR L P O O • • • •
Sidelight • P • • • • •
Borrowed Light O P O • • • •
Mechanical/Electric L • O O P • • •
Stairwell L • O • P • • •

Use of Frame: P = Preferred O = Optional • = not recommended
Frequency: H = High M = Medium L = Low


ACCESSORY HARDWARE

TA-10 Regular Arm Closer Reinforcement – Can be used on all Frames
TA-12 Parallel Arm Closer Reinforcement – Classic Frames only
TA-47 Parallel Arm Closer Reinforcement – Kerf Frames only
CASING RECOMMENDATIONS
TA-8 Standard Steel TA-23 Aluminum TA-28 Aluminum
casing for use in office applications


Download CSI Format Specifications
Print Office-Professional PDF

Classic Frame S C

Drawing for S, C Series Door Frames
S-Series
(20 gauge)

General use for all interior openings.

Minimum Jamb Depth – 2 5/8"

Maximum Jamb Depth – 5 3/8"

Fire Rating – 90 Minute (Minimum Jamb Depth 3 3/8" for rating)

Maximum Door Weight – 500 lbs.

C-Series
(18 gauge)

General use for all interior openings requiring additional strength and impact resistance of 18 gauge steel.

Minimum Jamb Depth – 2 5/8"

Maximum Jamb Depth – 13"

Fire Rating – 90 Minute (Minimum Jamb Depth 3 3/8" for rating)

Maximum Door Weight – 500 lbs.
Adjustable Frame A

Drawing for S, C Series Door Frames
A-Series
(18 gauge)

Use for interior openings with uneven or odd sized walls requiring non-stock wall size. Adjustable jamb thickness makes this frame Ideal for remodel projects.

Minimum Jamb Depth – 3 3/4"

Maximum Jamb Depth – 9 1/8"

Fire Rating – 90 Minute

Maximum Door Weight – 500 lbs.
Kerfed Frame CK

Drawing for S, C Series Door Frames
CK-Series
(18 gauge)

Use for interior and exterior openings requiring a seal against smoke, sound, weather, and light. Kerfed stop with factory installed seal.

Minimum Jamb Depth – 4"

Maximum Jamb Depth – 8"

Fire Rating – 90 Minute

Maximum Door Weight – 500 lbs.
